SF2104 Wheeled Tractor

SF2104 tractor product introduction

The power of Shifeng TG Series Tractor ranges from 130-210 HP, with high chassis strength and high operation efficiency.
There are seven models: sf1304, sf1404, sf1804, sf2004, sf1504, sf1604 and sf2104
TG series is equipped with Weichai III engine, high-pressure common rail technology and German original Bosch pump.
It is equipped with sand dust air filter and fuel water Hanbao. The starting system has time limited starting function.
32 forward gears and 24 reverse gears.
Front mounted retrograde gear, creeper gear and overdrive gear can be selected.
The main transmission shifts for the synchronizer.
The auxiliary transmission shifts gears for the meshing sleeve.
The main clutch is controlled by air assisted hydrostatic pressure.
The power output clutch is a push-button electro-hydraulic control, with 540, 760, 1000r / min and other speeds.
The service brake adopts wet and disc self reinforcing brake.
Equipped with four-wheel brake switch.
The front drive axle adopts Carraro integral axle housing structure.
Push button electro-hydraulic control separation and combination.
The lifter is a double oil cylinder external type, and the lifting system is equipped with a blockage alarm device.
The suspension system adopts imported quick change connector, and the electric control lifting system is optional.
Multi channel hydraulic output device.
High grade luxury seats fully reflect the humanized design.
Xinnong cab is equipped with optional cooling and heating air conditioning system.
Intelligent electrical instrument and sensing system are convenient for judging and troubleshooting.
